ISO/GMP Stainless Steel Pass Through Box for Laboratory Use Electronic Dynamic Passbox ประเทศไทย
- PRODUCT DETAILS
- RELATED PRODUCTS
PRODUCT DETAILS
SHP CLEANROOM PRODUCTS OVERVIEW
ABOUT PASS BOX:
Product information:
Pass box is a component of a clean room system that allows for transfer of items between two areas of differing cleanliness. These two areas can be two separate clean rooms or a non-clean area and a clean room. Utilizing pass boxes decreases the amount of traffic in and out of the clean room, which saves energy and lowers risk of contamination. Pass boxes are often seen in sterile laboratories, electronics manufacturing, hospitals, phar maceutical manufacturing facilities, food and beverage production facilities, and many other clean manufacturing and research environments.
| Specifications | Static pass box |
Dynamic Pass Box |
| Working dimensions |
400*400*400 500*500*500 600*600*600 or Customized |
400*400*400 500*500*500 600*600*600 or Customized |
| Material |
SS304, SUS304, SS Sheet, Thinck.=1.0mm, 1.2mm |
SS304, SUS304, SS Sheet, Thinck.=1.0mm, 1.2mm |
| Glass | Double Tempered Glass, Thick.=5mm | Double Tempered Glass, Thick.=5mm |
| Hinge | Mechanic/Electronic Interlocker Systerm | Mechanic/Electronic Interlocker Systerm |
| Power Supply | 220V, 50HZ | 220V, 50HZ |
| UV Light | YES | YES |
| Air Velocity | N/A | 0.3m/s-0.6m/s |
| HEPA | N/A | EU 14 grade with an efficiency of 99.995% for 0.3 mic. (GEL TYPE) |
| Prefilter | N/A | EU 4 grade with an efficiency of 90% for 10 mic. |
| Accessories | N/A |
PAO test port Of HEPA, High Efficiency Differential Pressure Gauge |
